Effective 30-40W RF Signal Jammer Module with Circulator for Wireless Communication Interference

Basic Information
Place of Origin: Shenzhen China
Brand Name: TeXin
Certification: CE ISO
Model Number: TX-30W customized
Minimum Order Quantity: 2
Price: Negotiable
Packaging Details: durable case or box
Delivery Time: 5-8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000/month
Detail Information
Chip: Industrial Grade Jammer Type: High Power Outdoor Drone Jammer Module
Customized: Multi Channel Frequency Working Temperature: -40~+65
Frequency: Customized Outshell: Aluminium
Power: 30 40W Dimensions Of Device: 140*49*12
Gain: 46 Packing: Box
Highlight:

RF Signal Jammer Module

,

30-40W Signal Jammer Module

,

Signal Jammer Module with Circulator


Product Description

Effective 30-40W RF Signal Jammer Module with Circulator for Wireless Communication Interference

The 30-40W RF Signal Jammer Module with Circulator has a power output of 30 to 40W. It can generate a strong RF jammer signal to effectively block RF communications within a specific range. A high-quality circulator is integrated to ensure one-way signal transmission and efficiently direct the emitted interference signal toward the target direction. The modules produced by TX are of guaranteed quality. Their excellent performance and good use effect make them popular among customers.



It supports interference with multiple common RF bands, including 2.4GHz, 5.8GHz, and other civilian wireless communication bands, as well as some specific professional bands.



Effective 30-40W RF Signal Jammer Module with Circulator for Wireless Communication Interference 0Effective 30-40W RF Signal Jammer Module with Circulator for Wireless Communication Interference 1



Product Specification



No. Item Data Unit
1 Frequency Customized MHz
2 Test voltage 24-28 V
3 Current 3 A
4 Output 30-40 W
5 Gain 46 dB
6 Output stability 1 dB
7 Connector SMA / Female
8 Output connector VSWR ≤1.30 (No power and VNA test)
9 Standard input 0-10DB
10 Power supply wire Red wire
11 Enable Control High ON Low Off
12 Out shell Size 140*49*12 mm
14 Weight 262 g
15 Work Temperature -40~+65
16 Out shell material Aluminum
17 Vibration need Carload OK



Effective 30-40W RF Signal Jammer Module with Circulator for Wireless Communication Interference 2

​FAQ

Do you have the self-development capacity to design a new and creative anti-drone solution?

yes, TeXin has the key know-how and thousands of project experience to offer a new anti-drone solution from shape to inside design according to customer-specific needs.

How many assemblies do you have in your factory?

TeXin factory has over 9 assemblies in our over 5000sqm 2-floor factory in Long area, Shenzhen city.

Do you have the engineer for the technical support when you are making the after-sales service?

TeXin engineering team can directly offer the customers technical support online anytime customers need it.

How can I be your distributor in our own country?

For the TeXin distribution authorization, we can offer it for some customers after the details negotiation, it depends on the real situation of each side.
