Name: High efficient 10W 20W coverage 500-7300mhz PA amplifier module for anti drone jammer system
Brand: Shenzhen TeXin electronic Co., Limited
SKU: TEXINPA020
Price: 4,014.00 USD
Availability: InStock

Detail Information

Brand:	TEXIN	Frequency:	500-6000MHZ (Customized)
RF Distance:	1.5-2 Km	Current:	2A
Power:	20W(customized)	Jammer Type:	UAV FPV Drone
Dimensions Of Device:	1056020mm	Packing:	Box
Working Temperature:	-40℃ To +80℃	Gain:	43dbm
Connector:	SMA	Weight:	0.323g
Voltage:	24V-28V
Highlight:	10W 20W PA amplifier module , 500-7300mhz anti drone jammer , wireless signal amplifier with warranty

Product Description

High Efficient 10W/20W Coverage 500-7300MHz PA Amplifier Module for Anti-Drone Jammer System

Product Introduction

The TEXINPA020 is Shen Zhen Texin Electronics Co., Ltd's newly designed PA power amplifier module. This 10W/20W PA power amplifier features broad band coverage from 500-7300MHz in a single amplifier, making it significantly more convenient to carry compared to regular amplifiers. It provides highly effective defense against FPV drones operating at 800MHz, 900MHz, 1200MHz, 2400MHz, 5200MHz, and 5800MHz frequency bands. Custom frequency or wattage requirements are available upon request.

Frequency: 500-7300MHz
Power: 10W/20W
Voltage: 28V
Current: 1.5A

Technical Specifications

No.	Item	Data	Unit
1	Frequency	500-7300	MHz
2	Test Voltage	28	V
3	Current	1.5	A
4	Output	20	W
5	Gain	43	dB
6	Output Stability	1	dB
7	Connector	SMA / Female
8	Output Connector VSWR	≤1.30 (No power and VNA test)
9	Power Supply Wire	Red+Black
10	Enable Control	High ON Low Off
11	Out Shell Size	1056020	mm
12	Mount Hole	105*60	mm
13	Weight	300	g
14	Work Temperature	-40~+125	℃
15	Out Shell Material	Aluminum
16	Vibration Need	Car load ok
17	Input	0-10dbm

Product Images

Key Features

500-7300MHz RF frequency coverage
20W output with low power consumption
Lightweight 300g design suitable for FPV jammer devices
Aluminum shell providing waterproof protection and excellent heat dissipation
Industrial grade construction with no built-in signal source
Capable of amplifying signals over long distances
Power amplifier with signal source compatibility

Usage Guidelines

Conduct testing before use
Always connect antenna when connecting power supply
Install separate close band modules when required
Use matching cooling device when output power exceeds high levels

Frequently Asked Questions

Are you an anti-drone module and jammer manufacturer?

Shenzhen TeXin Electronic Co., Ltd. has over 10 years of history in China. We independently develop and produce high-tech, professional anti-drone modules, anti-drone signal jammers, and drone detectors. We also offer antennas, heat sinks, and power supplies.

What is the customized frequency range and output power of the anti-drone jammer module?

TeXin anti-drone modules typically offer 5W to 300W output customization with frequency ranges from 100MHz to 6300MHz. The usual bandwidth is approximately 200MHz (for example, 2300-2500MHz). We can customize according to specific customer requirements even outside these ranges.

Can you show us the test photo and video of the FPV jammer module after we buy them?

Yes, TeXin will provide photos and videos of sample and mass production assembly and testing before delivery as requested by customers.

Tag:

Place of Origin:	Guang Dong china
Brand Name:	Texin
Model Number:	TEXINPA020

Minimum Order Quantity:	10
Price:	negotiate
Delivery Time:	5-8
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000per month
