Name: Teixn brand Voltage Controlled Oscillator VCO chip SM150 10dbm 5V Voltage Control Unit
Brand: Shenzhen TeXin electronic Co., Limited
SKU: SM150
Price: 147.00 USD
Availability: InStock

Detail Information

Product:	VCO Chip	Working Voltage:	5V
Operating Temperature Range:	-40°C~+85°C	Current Consumption(Icc):	25mA
Application:	Goverment, Speech Center, Church, Meeting Room, Etc.
Highlight:	Voltage Controlled Oscillator VCO chip , SM150 Voltage Control Unit , 5V Voltage Control Unit

Product Description

Teixn brand Voltage Controlled Oscillator(VCO) SM150 10dbm 5V operate

Model: SM150

Description
The VCO (Voltage Control Unit) is an indispensable component of an RF module, its main function being to up-convert (transmit) and down-convert (receive) RF signals. It is primarily used in base stations, mobile communications, and other RF equipment.

Performance characteristics

-Low noise;

-High frequency stability;

-Low voltage operation: +3.3 +5V;

-Operating temperature range: -40°C~+85°C;

-Small size.

Parameter		Mini	Typical	Max	unit	Remark
Working voltage (Vcc)		4.75	5.0	5.25	Vdc
Output Level			10		dBm	Vcc = 5.0 V
Current consumption(Icc)		--	25		mA
Tuning sensitivity (average)		10	--	--	MHz/V	Vt = 0.5~4.5 V
Tuning voltage (Vt)		0.5	--	4.5	Vdc
Phase noise/carrier	@1KHzOffset	--	-65		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@10KHzOffset	--	-92		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@100KHzOffset	--	-120		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@1MHzOffset	--	-130		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
Oscillation frequency		-- 175	-- --	135 --	MHz	Vcc = 5.0 V, Vt = 0.5 V Vcc = 5.0 V, Vt = 4.5 V
Tuning terminal capacitance		--	56	--	pF
Second Harmonic		--	--	-15	dBc
Load impedance		--	50	--	Ω
Operating temperature		-40	--	+85	°C

Order	Explanation
1	Voltage (VCC)
2	Ground (GND)
3	Tuning voltage(VT)
4	N.C
5	Ground (GND)
6	RF Out put

Packing list

Teixn brand Voltage Controlled Oscillator VCO chip SM150 10dbm 5V Voltage Control Unit 0
