High Gain Wifi RF Amplifier ESD Protection For VSAT Radios YP602528 Model

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: SGS, ISO9001
Model Number: YP602528
Minimum Order Quantity: 1
Price: Negotiation
Payment Terms: L/C, T/T, Paypal,etc.
Detail Information
Model: YP602528 Keyword: RF Amplifier
High Light:

radio frequency amplifier


mmic power amplifier

Product Description

TXtelsig YP602528 Wifi RF Amplifier


The YP602528 is a high-gain power amplifier based on the highly-reliable InGaP/GaAs HBT technology. It can be configured for high-gain applications with super power-added efficiency while operating over the 5.4~6.6 GHz frequency band. The YP602528 is assembled in at 16-pin, 4×4mm2, QFN package.



■ 5400~6600 MHz Frequency Range

■ +25dB Gain

■ +28dBm P1dB at 5.0V

■ 1.4% EVM@27 dBm for 802.16d 54Mbps, 6.0V

■ 270mA~310mA Quiescent Current

■ 3.3~5V Operation

■ <-10dB Input Reflection

■ ESD protection all ports above 1000V HBM

■ Advanced InGaP/GaAs HBT Technology


Electrical Specifications

The DC and AC specifications for the power amplifier interface signals. Refer to Table 2 for the Absolute Maximum Ratings. Refer to Table 3 for the Electrical Characteristics


Caution! ESD sensitive device.

Exceeding any one or a combination of the Absolute Maximum Rating conditions may cause permanent damage to the device. Extended application of Absolute Maximum Rating conditions to the device may reduce device reliability.



■ 802.11p WAVE (DSRC)

■ IEEE 802.11a/n & HiperLAN

■ IEEE 802.16 WiMax

■ VSAT Radios
