Type: | Cell Phone Jamming Device | Antenna: | Built In Antenna |
---|---|---|---|
Jamming Type: | 2G,3G, 4G,5G,Wifi,Customized | Customized Frequency: | 20Mhz-6.5Ghz By Different Country&customer Need |
Jamming Range: | 5-30 Meter | Marterial: | Durable Alluminum Alloy |
Size: | 400*360*195 Mm | Weight: | 7.0kg |
High Light: | cell phone frequency jammer,rf frequency jammer |
Powerful IPx4 WIFI Cell Phone Jammer , Customized Mobile Phone Signal Jammer
TX-LX7: is perfect for securing VIP convoy and important events 24hours non stop, powerful with
a wide effectively jamming range 5 to 30 meter. It can be easily used everywhere with a pretending
look of suitcase.
The "Frequency&Antenna" be customized by different country standard and specific need.
TXtelsig is the leading manufacturer to design and produce wireless jamming and coverage product.
Product Feature
1. A broad range of jamming bands of CDMA, GSM, DCS, 4G, 3G and PHS, etc. ; the frequency band
can also be customized as your options
2. Not influencing Base Station while cutting off only downlink signal with subsections of spectrum
3. Radius up to 5-30 meter to delete signal threat in the protected area all day long 24/7
4. IPx4 level be seriously waterproof and deal with terrible environment
5. Durable high quality aluminum alloy, also with strong dual heat-dissipation system to keep its body cool
and high-effective working
6. A pretending look of Suitcase can better camouflage
7. Portable be carried everywhere
8. Can be used on car or Linked with computer monitoring system
Specificaiton
TX Module No. | TX-LX7 |
Main Engine Size | 400*360*195mm |
Main Engine Weight | 10.4KG |
Working Temperature | —40 to 55℃ |
Jamming Range | 5-30 meter |
Working Time | 24 hours continuously |
Relative Work Humidity | 80% |
Power Supply | 150W |
Input Power | AC 100-240V DC 24V |
Storage Battery | built in 20A, lasts 70-90 minutes |
Antenna Data | built in orientation antenna gain 4-5dBi |
Warranty | 1 year and lifetime technical support |
Customized Frequency Options
CDMA | 851-894MHz |
GSM | 925-960MHz |
DCS | 1805-1880MHz |
PCS | 1930-1990MHz |
3G | 2110-2185MHz |
4G (LTE) | 725-785MHZ |
4G (Wimax) | 2300-2410MHZ |
Lojack | 167-175MHZ |
RF Radio | 315MHz |
RF Radio | 433MHz |
GPSL1/Glonass | 1575.42MHz |
VHF | 135-175MHz |
UHF | 435-475MHz |
GPSL2/Glonass | 1227.42MHz |
Wireless Camera 1.2G | 1100-1200MHz |
Wireless Camera 2.4G | 2400-2483MHz |
Wi-Fi/Bluetooth | 2.4G |
WI-FI, 5G | 5500-5900MHz |
Application
1. School, examination room, bank, library, museum, commanding center, bidding assembly hall etc.
2. Party and governmental Agency, conference meeting hall of various enterprises, music hall, theatres etc.
3. Detention house, labor reform criminal units, large, middle and small scale prisons, troops, courts, and
interrogation room etc.
4. Gas station, oil fields, gas entrainment station, oil bank, flame and explosion like warehouses
5. Others
