200W/300W Drone Signal Jammer Module Anti‑UAV Jamming System Module LDMOS 400‑2900MHz for UAV Countermeasure

Basic Information

Place of Origin:	Shenzhen, China
Brand Name:	TX
Certification:	ISO9001,SGS,CE
Model Number:	TX-B8H

Minimum Order Quantity:	1
Price:	Negotiated
Packaging Details:	Durable case or box
Delivery Time:	1-3 days
Payment Terms:	L/C, D/A, D/P, T/T,
Supply Ability:	10000pcs per month

Get Best Price Contact Now

Detail Information

Product Name:	Jammer Module	Model:	TXP200VLHN
Frequency:	Customized	Test Voltage:	28v
Current:	16A	Output:	300w
Gain:	53dB	Output Stability:	2dB
Connector:	N / Female	Output Connector VSWR:	≤1.40 (No Power And VNA Test)
Power Supply Wire:	Red+Black+Enable Wire	Enable Control:	High ON Low Off
Out Shell Size:	1809930mm	Color:	Silver
Weight:	1390g	Work Temperature:	-20~+70℃
Out Shell Material:	Aluminum	Vibration Need:	Car Load OK
Highlight:	8 Way Wifi Blocker Jammer , Two Fans wifi blocker jammer , Aluminum Alloy wifi jamming device

Product Description

High Power Anti‑Drone Jammer Module LDMOS 300W for UAV Countermeasure

Product Overview

This is a high-performance drone jammer module built with advanced LDMOS technology and a built-in circulator. It blocks signals in the 400–2900MHz range, and delivers up to 300W of power for strong, steady signal suppression.

It has excellent in-band flatness. With small offset between upper and lower sidebands, the output is stable and clean, maximizing jamming effectiveness while reducing unwanted interference.

The built-in circulator protects the module from reflected power, keeping it safe from mismatched loads or antenna faults. It is compact and rugged (175×91×28mm, 1390g), making it easy to integrate into portable, vehicle-mounted or fixed-site anti-drone systems. Both frequency range and output power can be fully customized to meet your specific anti-drone needs.

Bullet Points

✅ Drone Jammer Module

Built for anti-drone signal blocking applications, with clear use cases for UAV countermeasure systems.

✅ High Power Output

Up to 300W average power for strong, reliable signal suppression.

✅ Wide Frequency Coverage

Works across 400–2900MHz, covering common drone control and GPS bands.

✅ Even Jamming Performance

Excellent in-band flatness , with stable and signal output.

✅ Built-in Protection

Integrated circulator guards against reflected power, protecting the module from antenna faults.

✅ Compact & Rugged

175×91×28mm, 1390g, easy to integrate into portable, vehicle or fixed anti-drone setups.

✅ Customizable Options

Frequency range and output power can be adjusted to match your specific anti-drone need

Parameter

No.	Item	Data	Unit
1	Frequency	Customized	MHz
2	Test voltage	28	V
3	Current	16	A
4	Output	300	W
5	Gain	53	dB
6	Output stability	2	dB
7	Connector	N / Female
8	Output connector VSWR	≤1.40 (No power and VNA test)
9	Power supply wire	Red+Black wire
10	Enable Control	High ON Low Off
11	Out shell Size	1759128	mm
12	Color	Silver	mm
13	Weight	1390	g
14	Work Temperature	-40~+65	℃
15	Out shell material	Aluminum
16	Vibration need	Car load OK
