5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: ROHS
Model Number: YP352833
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: Inner Blister Package with K=K outer 5 layer Export Carton
Delivery Time: In 2 work day
Payment Terms: T/T,Paypal,Western Union, Etc.
Supply Ability: 200,000pcs/per month
Detail Information
Application: 5G Wireless Communication,Telecom,Satcom,etc Frequency: 3200 To 3800 MHz
Gain: 28dB Power: 33dB
Power Supply: 5V Advanced Technology: InGaP/GaAs (HBT)
High Light:

5V RF Power Amplifier

,

RF Power Amplifier MMIC

,

5G Wireless Communication MMIC RF Amplifier


Product Description

RF Power Amplifier MMIC For 3200 To 3800MHz New Radio 5G Wireless Application



The YP352833 from TXtelsig is a high integrated power amplifier MMIC intend, that operates from 3.2 to 3.8 GHz

ideal for a wider range of 5G wireless communication such as Telecom, Space, Aerospace, Military and Satcom, etc.



It provides a typical gain of 28dB and P1dB of 33dBm at 3.5GHz, its typical quiescent bias condition is 5.0V at 40mA.

It is manufactured on an advanced InGaP/GaAs Heterojunction Bipolar Transistor (HBT) process, and assembled in a 16-pin

4mm*4mm, QFN package, internally integrated with ESD protection unit.



General Parameters
Type  High Power RF Amplifier from 3.2 to 3.8 GHz
Model No. YP352833
Manufacturer TXtelsig
Configuration MMIC intend
Industry Application Signal Jammer;
Signal Booster;
Telecommunication;
Aerospace & Defense;
Industrial; Satcom; Space,etc
Frequency 3200 to 3800 MHz
Package Type QFN package
Operating Temperature -40 to +85  °C
Storage Temperature -40 to +150 °C
Certification  ROHS certified (Pb-free)



Other customized frequency RF amplifier is also available..Please click in catagory "RF amplifier " or contact us directly

for more information.



5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication 0



5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication 1



Details Parameter Specification Unit Condition ( Temp=+25°C)
  Min. Type Max.
Frequency range 3.2 3.5 3.8 GHz
Small signal gain   28   dB
Input Return loss   18   dB Pin=-20dBm
Output Return loss   9   dB Pin=-20dBm
Output power at 1dB compression   33   dBm
ACLR   -31.5   dBc Pout=28dBm
Operating voltage 3.5 5 5.25 V
Power added efficiency   37   % Pout=33dBm
Voltage for VREF1&2   2.85   V
Voltage for VREF3   2.8   V
Current for VREF1&2   5   mA VREF1&2=2.85V, VREF3=2.80V
Current for VREF3   3   mA VREF1&2=2.85V, VREF3=2.80V
Quiescent current   400   mA VREF1&2=2.85V, VREF3=2.80V
Operation current   1080   mA Pout=33dBm



5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication 2 5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication 3 5V RF Power Amplifier MMIC 3.2 to 3.8 GHz For 5G Wireless Communication 4

Outer Carton Size: 44*44*24cm /Inner Carton Size: 21*21*21cm /4 inner carton per outer carton

Inner carton weight: 1.76kg /Outer carton weight: 7.04kg

10000pcs per Inner carton   /40000pcs per Outer carton
Delivery time: in 2 day
