| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | SGS,ISO9001 |
| Model Number: | TX-H14K |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Durable case or box |
| Delivery Time: | In 2 work day |
| Payment Terms: | T/T,Paypal, Etc. |
| Supply Ability: | 100,000pcs/month |
| Type: | Wifi Bluetooth Signal Jammer | Antenna: | 14 Band (max To 16) |
|---|---|---|---|
| Jamming Type: | 2G,3G, 4G,5G,GPS,Wifi,Customized | Customized Frequency: | 20Mhz-6.5Ghz By Different Country&customer Need |
| Jamming Range: | 5-20 Meter | Marterial: | Durable Alluminum Alloy |
| Size: | 330*230*56 Mm | Weight: | 5.0kg |
| High Light: | wifi blocker jammer,rf signal jammer |
||
24 Hours Bluetooth Signal Jammer , Wifi Signal Scrambler With AC Adapter
TXtesig is an expert in the signal jamming and wireless coverage product.
TX-H14K This full spectrum jammer is with 14 channels and each channel has the RF output
power to shield dangerous signal according to your own need.
Product Feature
1. Single antenna is with 3-5W output power to block signals efficiently and each antenna’s
power can be adjusted single or together with others
2. Low noise fan and Aluminum alloy shell to endure high temperature environment
3. Effectively making subsections of spectrum, only interfering downlink and bring no interception
of the base station
Specification
| TXtelsig No. | TX-H14K |
| Type | 14 antennas signal jammer |
| Size | 330*230*56mm |
| Weight | 5.0kg |
| Power Supply | AC adapter |
| Shield Range | 5-20 meter (single antenna output power is 3-5W) |
| Shield Frequency | 2G 3G 4G GPS WiFi Customized |
| Humidity | 30%-95% |
| Running Temperature | -20℃ to +55℃ |
Shield Details
| Output port | Frequency | Average out- | Channel out- |
| putting power | putting power | ||
| 150MHZ | 135-200 MHz | 30dBm | 6dBm/30KHz(min) |
| 250MHZ | 200-300 MHz | 30dBm | 1dBm/30KHz(min) |
| 350MHZ | 300-400 MHz | 30dBm | 1dBm/30KHz(min) |
| 450MHZ | 400-500 MHz | 29dBm | -2dBm/30KHz(min) |
| 550MHZ | 500-600 MHz | 29dBm | -3dBm/30KHz(min) |
| 650MHZ | 600-700 MHz | 29dBm | 3dBm/30KHz(min) |
| 750MHZ | 700-800 MHz | 29dBm | -2dBm/30KHz(min) |
| CDMA | 851-894 MHZ | 30dBm | 3dBm/30KHz(min) |
| GSM | 925-960 MHZ | 30dBm | 3dBm/30KHz(min) |
| DCS | 1805-1990 MHZ | 30dBm | 3dBm/30KHz(min) |
| 3G | 2110-2170 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIMAX | 2300-2400 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIFI | 2400-2500 MHZ | 30dBm | 3dBm/30KHz(min) |
| 4G | 2620-2690 MHZ | 30dBm | 3dBm/30KHz(min) |
Application
1. School, Exam Room, Prison, Club, Government
2. Conference Room, Auditoriums, Law court
3. Cinema, Theater museum
4. Place where mobile and other signals are prohibited such as service station, military, hospital
border petrol, Customs, etc.
