Bidirectional wide band 10W 500-7300mhz 1000-6400mhz power amplifier module for anti drone jammer system
10W small size biddirectional power amplifier module support frequency band 500-7300mhz .It without signal source build in ,according to the use condition ,this 10W RF power amplifier module can customize frequency like 1000-6400mhz ,500-7300mhz in one module .Widely use in anti drone signal system ,communication field .The power amplifier moudle has high performance and wide band features ,for low-altitude field safety maintenance is a high-quality product.
Features:
- 0-10dbm input customized
- 32-34V voltage support
- Wide band 500-7300mhz opation
- Bidirectional two connector in S
- Light weight portable to carry
| No. |
Item |
Data |
Unit |
| 1 |
Frequency |
500-7300 |
MHz |
| 2 |
Test voltage |
32-34 |
V |
| 3 |
Current |
2 |
A |
| 4 |
Output |
10 |
W |
| 5 |
Gain |
40 |
dB |
| 6 |
Output stability |
1 |
dB |
| 7 |
Input stability |
0-10(option) |
dB |
| 8 |
Connector |
SMA/ Female |
| 9 |
Output connector VSWR |
≤1.30 (No power and VNA test) |
| 10 |
Power supply wire |
Red+Black+Enable wire |
| 11 |
Enable Control |
High ON Low Off |
| 12 |
Out shell Size |
180*100*19 |
mm |
| 13 |
Mount hole |
172*92 |
mm |
| 14 |
Weight |
278 |
g |
| 15 |
Work Temperature |
-40~+65 |
℃ |
| 16 |
Out shell material |
Aluminum |
| 17 |
Vibration need |
Car load OK |
Working and storage environment requirements
- Need working -40℃+65℃ environment
- operate voltage within in 32-34V (option)
- Use it before need connect antenna first
- Long range distance working 1.5-2km but no have any obstruction
- When working at high power, a heat sink needs to be installed
