| Place of Origin: | Guang Dong china |
|---|---|
| Brand Name: | Texin |
| Model Number: | TX-CZBX |
| Minimum Order Quantity: | 1 |
| Price: | US$5500-6000/pieces |
| Delivery Time: | 5-8 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000per month |
| Brand: | Texin | Working Distance: | 1.5-2km |
|---|---|---|---|
| Detect Range: | 360° | Power Consumption: | ≤670W |
| Frequency Customization: | 1.2G/1.5G/2.4G/5.8 G | Weight: | 38Kg(Exclude Antenna) |
| Working Temperature: | -40-55℃ | ||
| High Light: | 1.2G vehicle-mounted signal reapter,5.8G vehicle-mounted signal reapter,Anti Drone vehicle-mounted signal reapter |
||
Product Description
This is a 2 in 1 Anti drone model can use as portable trolley case jammer, also can use as vehicle-mounted jammer.come with two set of antenna, one for vehicle foldable, another for trolley case directly, the use method can be adjusted in time according to the needs. To solve this problem in the most economical way, no matter whether it is in car or portable, you have enough of this device.
specification
| signal | Frequency band | Modules qty | power | Amount power |
| 2.4ghz | 2400-2500MHz | 2 | 100W+30W | 130W |
| 5.8ghz | 5700-5900MHz | 4 | 30W*4 | 120W |
| 1.5ghz | 1570-1620MHz | 2 | 30W+30W | 60W |
| 1.2ghz | 1120-1260MHz | 2 | 30W+30W | 60W |
| Jammer box size | 670x510x535mm | |||
| Jammer weight | 38Kg | |||
| Working temperature | -40-55℃ | |||
| Relative humidity | ≤85% | |||
| Power consumption | ≤670W | |||
| Power supply | AC 100V-240V DC: 24V | |||
| battery | Built-in 40AH lithium battery, can be used for 70-90 minutes | |||
| antenna | high gain fiberglass omni 360degree | |||
| Switch contro | Switch handle | |||
| Equipment Box | Trolley Case | |||
Product performance
1. One product for two purposes, support for car and trolley case portability
2. With a remote control handle, you can also control the switch of the device and the lifting of the antenna in the car
3. The vehicle is equipped with an inverter, the antenna can be erected when in use, and the antenna can be placed on the roof of the car when not in use, unobtrusive and easy to enter the garage, and can better protect the antenna
4. The vehicle-mounted model has a shock-absorbing antenna, which can reduce the wear of the antenna during the driving process of the car
5. Support AC110-240 and DC 24V two power supply methods, you can choose the method you want through the knob switch
6. The main box design of the trolley box jammer is easy to move
7. Super dazzling LED power display, it is clear at a glance whether the battery power is sufficient
antennas sepcification
| FrequencyRange | 900-960/2400-2500/5150-5850MHz(customized) |
| Gain(dBi) | 8/10±1dBi |
| VSWR | ≤1.5/≤1.8 |
| Input Impedance | 50Ω |
| Maximum input power | 100W |
| Inpur connector type | N-K |
| Antenna weight | 0.4Kg |
| Operating temperature | -30～70 º |
