Detail Information

Product Name:	Cell Phone Signal Jammer	Type:	Cell Phone Signal Jammer
Rang:	100-200 Sqm	Size:	37011033mm
Weight:	2.3kg	Application:	School Examination Rooms, Teaching Classrooms, Dormitories, Various Social Examination Centers
Color:	White/black	Warranty:	1 Year
Highlight:	SM150 VCO Chip , VCO Chip For Jammer Module , RF Components VCO Chip

Product Description

Original VCO chip 300MHz 600MHz 800MHz SM150 for jammer module parts

The VCO (Voltage Control Unit) is an indispensable component of an RF module, its main function being to up-convert (transmit) and down-convert (receive) RF signals. It is primarily used in base stations, mobile communications, and other RF equipment.

2. Product Specification

Parameter		Mini	Typical	Max	unit	Remark
Working voltage (Vcc)		4.75	5.0	5.25	Vdc
Output Level			10		dBm	Vcc = 5.0 V
Current consumption(Icc)		--	25		mA
Tuning sensitivity (average)		10	--	--	MHz/V	Vt = 0.5~4.5 V
Tuning voltage (Vt)		0.5	--	4.5	Vdc
Phase noise/carrier	@1KHzOffset	--	-65		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@10KHzOffset	--	-92		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@100KHzOffset	--	-120		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
	@1MHzOffset	--	-130		dBc/Hz	Vcc = 5.0 V, Vt = 2.5 V
Oscillation frequency		-- 175	-- --	135 --	MHz	Vcc = 5.0 V, Vt = 0.5 V Vcc = 5.0 V, Vt = 4.5 V
Tuning terminal capacitance		--	56	--	pF
Second Harmonic		--	--	-15	dBc
Load impedance		--	50	--	Ω
Operating temperature		-40	--	+85	°C

3. Feature

-Low noise;

-High frequency stability;

-Low voltage operation: +3.3 +5V;

-Operating temperature range: -40°C~+85°C;

-Small size.

4. Application

Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts 0

Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts 1
