| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | TX |
| Certification: | ISO9001,SGS,CE |
| Model Number: | TX-NZ150W |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated |
| Packaging Details: | Durable case or box |
| Delivery Time: | 1-3 days |
| Payment Terms: | L/C, D/A, D/P, T/T, |
| Supply Ability: | 10000pcs per month |
| Product Name: | Cell Phone Signal Jammer | Type: | Cell Phone Signal Jammer |
|---|---|---|---|
| Rang: | 50-100m | Size: | 450*450*200mm |
| Weight: | 15kg | Application: | School Examination Rooms, Teaching Classrooms, Dormitories, Various Social Examination Centers |
| Color: | White | Warranty: | 1 Year |
| High Light: | GSM CDMA LTE phone Jammer,11 Channel Cellular Phone Signal Jammer,11 Channel Cell Phone Jammer |
||
High power GSM CDMA LTE Phone Jammer
1. Product Introduction
This high power GSM CDMA LTE phone Jammer can block the cellular phone signal 2g 3g 4g 5g, Wi-Fi, GPS signal and other specific signal with high average power 15W each
2. Specification
|
Mechanical Data |
|
|
Product Type |
TX-150W high power GSM CDMA LTE phone Jammer |
|
Jamming Range |
50-100 meter |
|
Working Channels |
11 channel customized |
|
Average Output Power |
15 W |
|
Total Output Power |
150W |
|
Coverage Area |
Horizontal 95° Vertical 35° |
|
Body Size |
450*450*200mm |
|
Body Weight |
15.0kg |
|
Working Temperature |
-20℃~75℃ |
|
Working Humidity |
35~95% |
|
Power Consumption |
≤240W |
|
Power Input |
AC160V~240V |
|
Power Output |
DC 24V/10A |
3. Product Feature
* Average High power each 15W, 11 channel, total 150W
* Single modulation of RF jamming module
* Massive MIMO antenna max 14dBi high gain each channel
* Long range 50-100 meter (-75dB, open environment, depends on BTS distance)
* Can shield 2/3/4/5g phone, Wi-Fi, GPS at same time
* On/Off control for Wi-Fi channel
* Precise voltage for stable work under large voltage fluctuation
* Original IC chip with strong power push and stable output power performance
* Steady structure: durable PVC and metal alloy back plate, anti broken, heat resistant, waterproof, dust proof
* Smart cooling system with built-in ultra thick heat sink, heat dissipation fin, large fans, ventilation holes at four sides; Ensure the fast cooling effect and long life span
* Easy installation by wall mount or desktop
* User friendly no harm to human health with this high power GSM CDMA LTE phone Jammer
4. Product Application
* Avoid the illegal phone use at Prison, Detention house, Police station, Law court, Procuratorate, etc
* Avoid the important document leaking or business secret leaking, such as in Real-estate transaction, Business conference room, Military Base and Important confidential site, Government sites, Administration Department, Criminal case on site checking, Law enforcement, Critical Security sites, etc.
* Avoid Hazardous place accidents caused by misuse of Phone Wi-Fi signals, such as Petrol station, Chemical factory, Oil depot, Hazardous substance storage warehouse and assemblies, etc.
* Avoid phone calls noise at Library, Movie theatre, Theatre, Concert hall, Memory hall, Auditorium, Church, etc.
*Avoid examination cheating in school, training classes, sports competition, etc.
* Avoid phone playing during working time; effectively avoid assembly injury and death accident for phone playing, improve working efficiency, such as Textile mill, Metallurgical plant, etc
