| Place of Origin: | China |
|---|---|
| Brand Name: | TeXin |
| Certification: | CE |
| Model Number: | JZ01 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated |
| Packaging Details: | Kraft paper carton K=K 5 layer with fumigation wooden case outside for exportation |
| Delivery Time: | In 2 work day |
| Payment Terms: | T/T,Paypal,L/C,D/A,D/P, Etc. |
| Supply Ability: | 5000pcs/month |
| Type: | UAV Defence System | Size: | 50*45*23 |
|---|---|---|---|
| Weight: | 25kg (not Including Antenna ) | Antenna: | 120cm High Gain Directional 15dBi |
| Protection Range: | 2000meter Radius | Umanned: | 24/7 Computer Monitoring |
| High Light: | Anti Drone UAV Defence System,15dBi UAV Defence System,2000m Airspace Security Signal Jammer |
||
Outdoor 360 Degree UAV jamming system
(2.4G 5.8G Version)
TX-JZ01 protect an important area from drone UAV attack in 3000 meter radius range.
When drones enter the area, it will be out of ground control, stop reconnaissance and return home.
(If add/press GPS, then the jammer can force the drone to land.)
Application Area
. Government: Prison, Military, Police, Border Control, Government Buildings, Detention Centre, Drug rehabilitation centers, Other Law enforcement
. Critical Infrastructure: Chemical Industry,Oil Depot,Oil Refinery, Gas Station Power generate plants,Nuclear power plants,Water control center, Reservoir
. Mass Event: Sports Stadium&Events, Important Meetings, Entertainment Performance
. Museums, Campus,Theatre,Church,Hospital
. Scientific research center,Security Service,Test Facilities
Feature
1. High power shield drone in 3000 meter radius
(depends on real environment)
2. On/off control for each channel
3. Channel frequency&quantity is customized from 2 to 8 channel
4. PLL synthesized signal source and Separate module configuration
for easy control and maintenance
5. IP55 aluminum alloy cabinet: be waterproof, dust proof
heat-resistant shockproof, anti-corrosion
6. Smart cooling system with built-in ultra thick heat sink
large fans and air inlet&outlet, to ensure the machine long time stable work
7. Long time operation 24/7 all day all weather
8. High gain directional antenna 15dBi 4pcs
help 360 degree coverage no blind corner
9. HuaWei Thunder Protection Box
10. VSWR Protection
11. Can have Ethernet/LAN remote control with extra cost
| UAV Defense System -Cabinet Specification | |
| Shield Frequency Range * UAV remote control signal * Reconnaissance data transmission signal |
Band1: Wi-Fi 2.4GHz : 2400-2500 MHz |
| Band2: Wi-Fi 5.8GHz : 5725-5850 MHz | |
| Customized | |
| Jamming Technique | Radio Frequency Sweep Jamming |
| Electric Field | Compatible with Icnirp Standard |
| Farthest Shield Range | 3000 meter radius, depends on real environment |
| Remote Control Connection | RJ45 or RJ485 (extra cost ) |
| Working Time | 24 hours 7 days continuously |
| Water&Dust Proof Level | IP55 level |
| Out shell Material | Aluminum Alloy |
| Product Size | 50*45*23cm |
| Product Weight | 35kg |
| Output Power | 280 W |
| Power consumption | 380 W |
| Power supply | AC Adapter 110-220V |
| Working temperature | -20 ° ~ +85 ° |
| Relative humidity | 35～85% |
| Installation | Wall Mount or Pole Holding |
| Suggest Installation Height | 3-15m |
|
|
|
| High Gain Directional Antenna - Specifiation | |
| Dimensions mm(Height/Width/Depth) | 1200*420*125mm |
| Packing size(mm) | 1300*550*200mm |
| Antenna weight(kg) | 6.5Kg |
| Frequency Range | According to jammer frequency |
| Gain | 16±1dBi |
| VSWR | ≤1.5 |
| Polarization | Vertical |
| Horizontal Beam-width(0º) | 100±5º |
| Vertical Beam-width(0º) | 15±3º |
| Front-to-back ratio(dB) | ≥25 |
| Input Impedance(Ω) | 50Ω |
| Maximum input power(W) | 100W |
| Input connector type | 4 ports N/F |
| Lightning Protection | DC Ground |
| Rated Wind Velocity(m/s) | 60m/s |
| Operational Humidity(％) | 10- 95 |
| Ra-dome Color | Gray Color |
| Ra-dome material | UPVC |
| Operating temperature(ºC) | -30～85 º |
| Installation Method | Pole Mount |
| Mounting hardware(mm) | ￠40～￠80 |
| Mechanical tilt(º) | 0-10º |
Product Analysis
| 1 |
|
IP55 Outdoor Waterproof Cabinet | 1pcs |
| 2 | |
Single Modulation High Power
WiFi2.4G: 2400-2485MHz 20W 1pcs |
4 pcs (built in the cabinet ) |
| 3 | |
Industrial grade Power supply Box&Wire&Plug |
1pcs (built in the cabinet ) |
| 4 | |
Ultra Heatsink | 1pcs (built in the cabinet ) |
| 5 | |
Efficient heat dissipation fans | 4pcs (built in the cabinet ) |
| other necessary wires etc. to make up it |
| 6 | |
120cm high gain 16dBi antenna | 4pcs (360 degree coverage ) (outside the cabinet ) |
| 7 | |
1/2 Ultra flexible coaxial cable | 32 meters (outside the cabinet ) |
| 8 | |
Huawei Thunder Protection Box /SPM60A |
1 pcs (outside the cabinet ) |
| 9 |
|
Waterproof Insulation Tape | 2 pcs (outside the cabinet ) |
| 10 |
2/3/4 Way Optional |
Power Sp-litters | 3pcs (outside the cabinet ) |
Package
* Durable 5 layer K=K Kraft paper carton with protection foam and outer
fumigation wooden case for Jammer Cabinet
* Durable 5 layer K=K kraft paper carton with protection foam
Customized Option
* Frequency band and quantity
* Logo service
* Outshape design and mold
* Software engineering
Service
* Two year warranty and Life-time technical support
* Direct discussion with the mechanical and software engineer team
* Compatible with your current security system
* We can offer the installation photo, video or online training free of charge
* We can offer the local installation service with extra cost
* We can offer the upgrade service for hardware and software
