4 Directional Antennas Drone Frequency Blocker Long Distance 1000-3000 Meter

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: SGS,ISO9001
Model Number: TX-JZ01
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Box With PE Foam
Delivery Time: 2 work days
Payment Terms: L/C, T/T, PayPal, etc.
Supply Ability: 50,000pcs/month
Detail Information
Type: Large Fixed Dorne Jammer Rated Voltage: AC 110V/240V (switchable)
Rated Power: 300W Output Power: 190W
Frequency: 2.4G, 5.8G, GPS L1 Jamming Range (radius): 1000 ~ 3000 Meter
Installation: Wall Hanging Or Pole Holding Antennas: 4 Directional Antennas
Net Weight: 35Kg(include Antenna) Keyword: 2.4 Ghz Frequency Jammer
High Light:

drone frequency jammer

,

drone frequency scrambler


Product Description

Long distance 1000-3000 meter drone jammer for 24 hours non stop use



TX-JZ01 fixed drone jammer is a device that can protect an area from UAV’s disturb.

The jamming radius is up to 3000 meters, and 360-degree coverage.

It is the ideal protection solution for critical locations and installations.







360° Omni-Directional Interceptor

The 4 directional antennas are set in four directions. Each antenna has a shielding range (horizontal) of 90°, giving 360-degree Omni-directional for convenient use. Blocker drone signal immediately after switching on. No need to aim.

The jammer usually installs on the roof or other high places for easy form a complete defense system.



4 Directional Antennas Drone Frequency Blocker Long Distance 1000-3000 Meter 0



The TX-JZ01 jammer system control radius at least 500~3000 meter, the factors as follows:

  1. The distance between the drone and remote control
  2. If there are obstructions between the drone and antenna
  3. The drone type, special frequency-hopping drone the radius may about 500 meter ordinary UAV control radius over 1000meters



4 Directional Antennas Drone Frequency Blocker Long Distance 1000-3000 Meter 1


The jammer main for frequency 2.4G, 5.8G, and GPS(1.5G), if you need other frequency please contact us to customize.



Channel Quantity Frequency Output power
1.5G 1 1550~1580MHz 47 dBm±1
2.4G 1 2400~2500MHz 50 dBm±1
5.8G 2 5700~5900MHz 43 dBm±1
5.1G Customizable of needs
1.2G



There are three buttons on the main host case 2.4G(2400), 5.8G(5700), GPS(1.5G), the next is a form about the different result of different status

Button Status

Results

2.4G/5.8G ON Drone fored returning
GPS OFF
2.4G/5.8G OFF Drone in Pose Mode
GPS ON
2.4G/5.8G ON Drone forced landing
GPS ON

GPS(1.5G) channel affect the normal use of civil aviation

communication, phone or vechile GPS navigation.
Please use with caution!



The basic parameter of jammer TX-JZ01

Basic Parameters
Model TX-JZ01
Jamming radius 500-3000 meter
Output 190W
Power consumption 380W
Size 530*410*230
Antenna size  1240*280*80(7.3Kg/per)
package size 850*550*400
Net Weight 35Kg(include antenna)
Ambient Temperature -40℃~55℃
Relative Humidity 35~85%
Installation ways Wall hanging/pole holding
Installation Height 3~15m
Shell material Aluminium alloy



Precautions

  • ◎ The jammer is designed to be waterproof and can be installed indoors and outdoors. Before use, it must be ensured that each output port is connected to the antenna without any error. (The long-term no-load of the port will cause equipment damage)
  • ◎ Do not turn on the power before the antennal installed. And forbidden to remove the antenna when the host is working.
  • ◎ The jammer should be installed in a well-ventilated and No obstruction place to ensure the shielding effect.
  • ◎ Installing outdoor, please caution that the connector should be waterproof and avoid exposure.
  • ◎ Adjust the angle of the antenna to cover the area you aim to.





Main for misused drones

Drones have become an integral part of our lives. They provide filmmakers with spectacular images and deliver urgently needed medicines to remote areas. But when misused, they can cause damage in the millions. This has driven up the demand for highly effective and reliable drone defense systems TX Fixed Anti Drone System

The growth of the civil drone market has resulted in criminal entities increasingly utilising low cost Unmanned Aerial Vehicles (UAVs), known as drones, to threaten Critical National Infrastructure, prisons, airports and other sensitive sites where traditional security measures are easily defeated. These small and extremely agile platforms can be used to deliver contraband, capture intelligence and potentially deploy explosives without detection.

4 Directional Antennas Drone Frequency Blocker Long Distance 1000-3000 Meter 2
