Type: | PAN-TILT Anti-Drone System | Frequency: | 2.4G 5.8G GPS Or Customized |
---|---|---|---|
Output Power: | 2.4G/100W 1.5G/50W 5.8G/40W | Jamming Range: | 500-3000 Meter |
High Light: | drone frequency jammer,drone frequency scrambler |
The TX-CZ02 vehicle-mounted defense system is mainly used to prevent emergency emergencies. The emergency vehicle control system has been designed and developed. The system adopts advanced vehicle improvement technology, radio and television detection and tracking technology, electromagnetic suppression technology, computer communication technology and image processing technology. , formed a mobile vehicle control center.
TXtelsig's anti-UAV system is designed for the "low-small and small" UAVs with low flying height, slow moving speed and small radar scattering area. It combines active and passive radar, visible light, infrared and other detection methods, and takes various measures from Communication, navigation, and mission load are used to interfere with drones, limit the flow of information to the limit, and realize effective detection, monitoring, and combat of drones throughout the day and around the clock, thereby eliminating threats to important targets.
When the UAV intrusion is detected, the UAV Interference System automatically adjusts the frequency and direction of the electromagnetic interference to implement precise electromagnetic interference to achieve drone and forced landing in the control area. It can realize UAV monitoring, detection and tracking in the 8km range, and its effective range can reach 13km in an open environment.
The detection device can automatically track the active target in the detection area, display the motion track of the active target reported in the defense area in real time through the monitoring screen, and perform image recognition, display and storage through the photoelectric tracking system. The system can display the monitoring front-end detection and monitoring range on the electronic map. Target coordinate information can be provided through linkage of various front-end detection devices, and the position information and real-time motion trajectory of the target can be displayed in real time. It is also possible to manually set multiple alarm zones and alarm lines of any shape on the electronic map, and to perform automatic sound and light alarms on the moving targets in the alarm zone and over the alarm line.
Jamming Frequency Details
Band |
Frequency |
Output Power |
1.5G(GPS) |
1580-1620 MHZ |
50W |
2.4G |
2400-2460MHZ |
100W |
5.8G |
5720-5850 MHZ |
40W |
