Indoor 150W Phone GSM CDMA 60 Meter 5G Signal Jammer

Basic Information
Place of Origin: China
Brand Name: TeXin
Certification: SGS, ISO9001
Model Number: TX-NZ150W
Minimum Order Quantity: 1
Payment Terms: T/T, L/C, Western Union, paypal, Alibaba
Detail Information
Name: High Power 5g Phone Signal Jammer Channels: 11 Output Channels
Antenna: High Gain Massive Antenna Jamming Range: 20-60 Meter
Frequency: GSM CDMA LTE 2G 3G 4G 5G WIFI Customize Support Network Control: With Network Control Port, Support Computer Control
High Light:

60 Meter 5G Signal Jammer

,

GSM CDMA 5G Signal Jammer

,

240W Wifi Jammer Device


Product Description

5G Signal Jammer High Power Long Distance Phone Signal GSM Wifi Jammer Device with computer romote control



TX-NZ150W is a self-developed wall-mounted Phone WiFi signal jammer. It is made of the antenna, RF Amplifier Unit, Multiplexer, Main Control Board, Smart cooling system, Power Supply system.

Its main feature is the ultra high gain antenna. The traditional jammer usually shares a high gain antenna for all channels or uses a small gain 5dBi or 9dBi antenna for each channel. But NZ-150W can transmit a high gain 14dBi signal in each channel and have a stable long-distance jamming effect.



signal jammer specification

Model TX-NZ150W
Frequency Range 850/900/1800/2100/2300/2600/wifi2.4ghz/wifi5.8ghz/gpsL1
Jammer Size 450*450*200mm
Body Weight 17.0kg
Working Temperature -40℃~55℃
Working Humidity 35~85%
Power Consumption ≤240W
Power Input AC160V~240V
Power Output DC 24V/10A
Installation Height 1.8~2.5m
Installation Environment Indoor, Etc
Switch Master switch +GPS switch+ wifi switch
Network Control Yes, with RJ-45 control port



jammer antenna specification

Frequency Range 800-960/1800-1920/2000-2500/2500-2700/5700-5900 frequency customize support
Gain 10.5/13/14 ± 1dBi
VWSR ≤1.5
Polarization 土45°
Horizontal Beamwidth 95士5°
Vertical Beamwidth 35±10°/35±10°/15±10°
Front to back ratio ≥23
Isolation ≥25
Input Impedance 50Ω
Max Output Power 100W
Connector Type 10*SMA-J
Thunder Protection DC Ground



phone signal jammer application
1)Avoid the illegal phone use at Prison, Detension house, Police station, Law court, Procuratorate,etc
2)Avoid the important document leaking or business secret leaking, such as in Real-estate transaction, Business conference room, Military Base and Important confidential site, Government sites, Admistration Department, Criminal case on site checking, Law enforcement, Critical Security sites, etc.
3)Avoid Hazadous place accidents caused by misuse of Phone Wifi signals, such as Petrol station, Chemical factory, Oil depot, Hazadous substance storage warehouse and assemblies, etc.
4)Avoid phone calls noise at Library, Movie theatre, Theatre, Concert hall, Memory hall, Auditorium, Church, etc.
1)Avoid examination cheating in school, training classes, sports competition, etc.
2)Avoid phone playing during working time; effectively avoid assembly injury and death accident for phone playing, improve working efficiency, such as Textile mill, Metallurgical plant, etc.

Indoor 150W Phone GSM CDMA 60 Meter 5G Signal Jammer 0







Indoor 150W Phone GSM CDMA 60 Meter 5G Signal Jammer 1



Indoor 150W Phone GSM CDMA 60 Meter 5G Signal Jammer 2
