Frequency Range: | 225~512MHz | Gain (Typ): | 44dB |
---|---|---|---|
Output Power (Typ): | 39dBm | Quiescent Current: | 60mA |
Highlight: | rf power amplifier,mmic power amplifier |
TXtelsig YPM02054439 RF Amplifier 225~512MHz 8W Power Amplifier Module
The YPM02054439 is a high-gain, high-power, and highly integrated Power Amplifier Module (PAM) intend for TETRA Communication requiring up to 8W output power. The PAM provides a typical gain of 44 dB and output power of 8W with CW signal input, typical quiescent bias condition is 28V at 60mA, the input and output are internally matched and require a minimum of external matching components, it is internally integrated with power detected unit and ESD protect unit. The YPM02054439 is housed inside a miniature 8-lead, 10×10×1.1mm3 LGA package.
Features
■ 225~512MHz Frequency Range
■ 44dB Gain (Typ)
■ 39dBm Output Power (Typ)
■ ≥15dB Input Return Loss
■ 28V Operation
■ 60mA Quiescent Current
■ Input and Output Internally Matched
■ Internally Integrated Power Detected Unit
■ Integrated ESD Protection Unit
■ Advanced InGaP/GaAs HBT and GaN pHEMT Technology
■ LGA Package 10×10×1.1mm3
Applications
■ TETRA
■ RADIO MODEM
Ordering Information
■ YPM02054439 225~512MHz Power Amplifier Module
■ YPM02054439-EVB 225~512MHz YPM02054439 Evaluation Board
Caution! ESD sensitive device
ESD Rating: Class1C
Value: Passes≥1000V min.
Test: Human Body Model (HBM)
Standard: JEDEC Standard JESD22-A114
ESD Rating: Class IV
Value: Passes ≥1000V min.
Test: Charged Device Model (CDM)
Standard: JEDEC Standard JESD22-C101
MSL Rating: Level 3 at +260 °C convection
reflow
Standard: JEDEC Standard J-STD-020
Parameter | Rating | Unit |
Input RF Power | 0 | dBm |
1st Stage Supply Voltage | -0.5 to +6.0 | V |
2nd Stage Supply voltage | -0.5 to +28.0 | V |
1st Bias Voltage | -0.5 to +3.3 | V |
1nd Bias Voltage | -5.0 to -2.0 | V |
Operating Ambient Temperature | -40 to +85 | °C |
Storage Temperature | -55 to +150 | °C |
Pin Description | ||
Pin No. | Symbol | Description |
1 | RF IN | RF input |
2 | VB | 1st bias voltage |
3 | NC | No connect |
4 | VG | 2nd bias voltage |
5 | RF OUT | RF output |
6 | VDD | 2nd stage supply voltage |
7 | PDET | Power detector |
8 | VCC | 1st stage supply voltage |
9 | GND | Ground connect |
