1.6GHz 6W Integrated Rf Linear Amplifier Module 24DB Gain Easy Operation YP162437

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: SGS, ISO9001
Model Number: YP162437
Minimum Order Quantity: 1
Price: Negotiation
Payment Terms: L/C, T/T, Western Union, Paypal,etc.
Detail Information
Frequency Range: 1500-1700MHz Gain (Typ): 24 DB
Output Power: 6W Quiescent Current: 80mA
High Light:

rf power amplifier

,

radio frequency amplifier


Product Description

TXtelsig YP162437 RF Amplifier 1.6GHz 6W Power Amplifier Module



The YPM162437 is a high-power highly integrated Power Amplifier Module (PAM) intend for Compass Satellite Communication requiring up to 5W output power. The PAM provides a typical gain of 24 dB and output power of 6W with pulse signal input, typical quiescent bias condition is 5.0V at 80mA, the input and output are internally matched and require a minimum of external matching components, it is internally integrated with ESD protect unit. The YPM162437 is housed inside a miniature 6-lead, 10×10×1.1mm3 LGA package.



Features
■ 1.5~1.7GHz Frequency Range
■ 24dB Gain (Typ)
■ 6W Output Power with Pulse Signal Input (Typ)
■ ≥20dB Input Return Loss
■ 5.0V~6.0V Operation
■ 80mA Quiescent Current
■ Integrated ESD Protection Unit
■ Minimum External Components
■ Advanced InGaP/GaAs HBT Technology
■ LGA Package 10×10×1.1mm3



Applications
■ Satellite Communication
■ Satellite Navigation



Ordering Information
■ YPM162437 1.6GHz Power Amplifier Module
■ YPM162437-EVB 1.6GHz YPM162437 Evaluation Board



Caution! ESD sensitive device
ESD Rating: Class1C
Value: Passes≥1000V min.
Test: Human Body Model (HBM)
Standard: JEDEC Standard JESD22-A114



ESD Rating: Class IV
Value: Passes ≥1000V min.
Test: Charged Device Model (CDM)
Standard: JEDEC Standard JESD22-C101



MSL Rating: Level 3 at +260 °C convection
reflow
Standard: JEDEC Standard J-STD-020



Parameter Rating  Unit
Input RF Power 15 dBm
Supply Voltage  -0.5 to +8.0
Bias Voltage  -0.5 to +3.0
DC Supply Current 3500 mA
Operating Ambient Temperature  -40 to +85 °C
Storage Temperature  -40 to +150 °C





Pin Description
Pin No.  Symbol  Description
1 RF IN RF input
2 VREF  Bias reference voltage
4 RF OUT RF output
5 VCC Supply voltage
3,6 NC No connect
7 GND Ground connect
