Type: | Wireless Signal Jammer | Antenna: | 12 Band (max To 16) |
---|---|---|---|
Customized Frequency: | 20Mhz-6.5Ghz By Different Country&customer Need | Jamming Type: | 2G,3G, 4G,5G,GPS,Wifi,Customized |
Jamming Range: | 5-20 Meter | Marterial: | Durable Alluminum Alloy |
Size: | 290*230*56 Mm | Weight: | 4.0kg |
Highlight: | wifi jamming device,wifi signal scrambler,12 antenna wifi wireless signal jammer |
12 antenna wifi wireless signal jammer for RF frequency blocker Mobile Cell Phone GPS
TX-H12K can block various kinds of wireless communication like WiFi, CDMA, GSM,2G, 3G, 4G 5G LTE
GPS, UHF, VHF and Bluetooth.
Product Feature
1. Each antenna has an output power of 5watt and total 60watt to block the target signal in 50meter
2. The power of each antenna can be adjusted or turned off dependently.
3. This device can be monitored by the centralizing management system.
4. Nice aluminium alloy and inner fans helps the heat-dissipation and stable performance 24 hour all day
long
5. Easily used in car with charger
6. Easy to install and use: attach the plug and antenna then put on the power.
7. The 4 to 16 antennas can be customized from 20MHZ to 6.5Ghz
8. Especially used for school, church,university, hospital, gas station,etc.
Specification
TXtelsig No. | TX-H12K |
Type | 12 antennas signal jammer |
Size | 290*230*56mm |
Weight | 4.0kg |
Shield Range | 5-20 meter (depends on phone signal environment) |
Shield Frequency | 2G 3G 4G GPS WiFi Customized |
Shield Details
CDMA | 851-894MHz |
GSM | 925-960MHz |
DCS | 1805-1880MHz |
PCS | 1930-1990MHz |
3G | 2110-2185MHz |
4G (LTE) | 725-785MHZ |
4G (Wimax) | 2300-2410MHZ |
Lojack | 167-175MHZ |
RF Radio | 315MHz |
RF Radio | 433MHz |
GPSL1/Glonass | 1575.42MHz |
VHF | 135-175MHz |
UHF | 435-475MHz |
GPSL2/Glonass | 1227.42MHz |
Wireless Camera 1.2G | 1100-1200MHz |
Wireless Camera 2.4G | 2400-2483MHz |
Wi-Fi/Bluetooth | 2.4G |
WI-FI, 5G | 5500-5900MHz |
4G LTE 2600 | 2620-2690MHz |
Application
1. Movie, Theatre, Hospital, Religion Places, Churches
2. School, University, Class room, Libraries
3. Prison, Police forces, Military and Government
4. Petrochemical Industry
5. Sports V enues
6. VIP convoy protection
7. Bomb Prevention&Disposal
Whip Antenna Details
Electrical Specifications | |
Frequency Range | The same as the jammer channel |
Impedance | 50 Ohm |
VSWR | <1.5 |
Gain | 3-5dBi |
Polarization | Vertical |
Radiation Direction | Omni |
Max. Power Input-watts | 50 W |
Mechanical Specifications | |
Length | 450mm |
Radiating Material | Whip |
Connector | SMA |
color | Black |
