2G / 3G / 4G Mobile Signal Booster , Wide Coverage Area Cell Reception Booster

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: SGS,ISO9001
Model Number: TX-3W-3P
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Durable case or box
Delivery Time: In 2 work day
Payment Terms: T/T,Paypal,Western Union, Etc.
Supply Ability: 100,000pcs/month
Detail Information
Type: Phone Signal Booster Repeater Coverage Area: Up To 1000m²
Gain: 70dB Frequency Range: Tri Band (customized)
Frequency Options: 800,900,1800,1900,2100,2600MHZ Or Customized Product Size: 229*169*53mm
Weight: 2.5Kgs Feature: No Interference To BTS
High Light:

dual band signal booster


cellular signal booster

Product Description

High Gain Three Band Phone signal booster repeater for powerful 2G 3G 4G wide coverage

TX-3W-3P is a high effective signal repeater to efficiently draw the outdoor signal into the indoor

blind area such as commercial building, villa and remote area Etc., from 300m² to 3000m² with

1-10 ceiling antennas.

TXtelsig has over 10 years experience in signal jamming and wireless coverage product.



1. High-end IC offers it a high power to absolutely strengthen the wireless 2G 3G 4G to a full

    status; also supporting a true three-band wide signal coverage

2. Practical three-band design to booster various kinds of phone signal, also with customized

    options among 800Mhz, 900Mhz, 1800Mhz, 1900Mhz, 2100Mhz, 2600Mhz, etc.

3. Accept over 300 phones calling&surfing the internet at the same time in nice signal environment

4. Wide coverage to 300m² when only 1 ceiling antenna and up to 3000m² with 10 extra Ceiling


5. The ceiling antenna way avoids the walls blocking and shielding phone signal

6. 27strips design on the aluminum alloy highly assist with the heat-dissipation to maintain the

    device at a low temperature and stably operate continuously 24/7

7. Manual ATT switch control to adjust the gain according the real need, then not interfering other

    people’s phone use

8. Each switch has a indication light to show its status

9. Various application for restaurants, conference, warehouse, residential area, mountain area

    home use, etc


Customized Three Band

For example, 800-900-2100Mhz, 800-900-1800Mhz, 900-1800-2100Mhz, or other options not

in this sheet


Band Frequency
3G 2100MHZ



Radiation Power 23dBm ALC  <=30dB
Main Device Gain 80±5DB Standing Wave <2.0
Coverage <=3000m² Noise Figure <5dB
In Band Antenna 1 to 6 3rd Order IMD >-45dBc
Size 229*169*53mm In Band dBp-p <5dB
Power Consumption <10W Impeadance 50Ω
Weight 3.0KG AC adapter AC: 110-240V
Joint N-Joint




1* signal booster

1* AC adapter

Accessory Choice of 1*ceiling antenna, 1*feeder line and 1*Log Periodic Antenna and other

customized options
