| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | SGS,ISO9001,ROHS |
| Model Number: | TX-JZ01 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated |
| Packaging Details: | Fumigation wooden case with alluminum alloy frame |
| Delivery Time: | In 2 work day |
| Payment Terms: | T/T,Paypal, Etc. |
| Supply Ability: | 5000pcs/month |
| Jamming Frequency: | Customized | Jamming Range: | Up To 3000 Meter |
|---|---|---|---|
| Size: | 53*41*23cm | Weight: | 35kg (not Including Antenna) |
| Case Type: | Die Case Alluminum Alloy | Output Power: | High Power 650W (customized) |
| Highlight: | 650W Cell Phone Signal Disruptor,Aluminum Alloy Cell Signal Disruptor |
||
High Power Drone Phone Wifi Signal Jammer For Prison Security
This TXtelsig JZ01 is a high power outdoor cellpone GPS Wifi
Jail Military Base RF signal jamming system.
Shield range: 360 degree coverage, 200-300meter (3000meter for drone)
Shield signal: 2g, 3g, 4g, 5g, Wifi, VHF, UHF, drone, GPS, etc. iDen, TDMA, CDMA, GSM, UMTS, DCS, PHS, PCS, 3G,4G LTE,5G, Wi-Fi ,Bluetooth,GPS AMPS, N-AMPS, NMT, TACS, etc. (1-18 channels can be modified or added )
Output power: 190W (Max 650W )
Antenna: 4 directional antenna
Case: IP65 waterproof level die cast aluminum alloy
Network connection RJ45: computer, APP, drone detection system
* Efficient cooling system ensures long working hours
* We self also develop RF jammer modules, VCO, Gain Block, Other Accessories with wholesale competitive cost and fast delivery.
| Model | JZ-01 Drone Phone Wifi Signal Jammer |
| Jamming frequencies | Cell Phone |
| WIFI | |
| GPS | |
| Drone , Other customized | |
|
1-18 Channels by different country and specific need) |
|
| Jamming radius |
1) 200-300meter for Cell Phone Signal,etc 2) 2000-3000meter for Drone Signal etc. |
| Power supply | AC Power plug |
| Total output power | 190W or customized (can > 650W) |
| Voltage | AC100-240V DC12V |
| Operating temperature | -40℃ to +70℃ |
| Operating humidity | 5% to 80% |
| Device size | 53*41*23cm |
| Device weight | 35kg ( not including antenna ) |
* 4pcs 360 degree High gain 16dBi directional antenna
* IP65 level bad environment protection Die cast aluminum alloy case
* RF jamming modules inside with original integrated circuit
* Other accessories available
* Real Scene Installation Photo
|
|
