Customized 100W 200W RF Jammer Module For Different Frequency

Basic Information
Place of Origin: China
Brand Name: TX TELSIG
Certification: CE FCC ROHS iso9001 SGS
Model Number: TX-RF100
Minimum Order Quantity: 1
Price: Negotiated
Payment Terms: T/T,Paypal,Western Union, Etc.
Supply Ability: 10,000pcs/month
Detail Information
Max Output: 200W Voltage: 24V Or Customized
Product Size: 220*115*25mm Box Size: 260*135*40mm
Weight: 1.03
High Light:

200W Signal Jammer Module

,

Drone Signal Scrambler Module


Product Description

Customized 100W 200W RF Jammer Module For Different Frequency







No. Item Data Unit Note
1 Frequency CDMA/GSM850 :850-894
GSM900 :925-960
GSM/DCS1800 :1805-1880
3G/UMTS2100 :2110-2170
4GLte700 :790-826
4G/WiMAX2600 :2620-2690
WIFI2.4G:2400-2485
4G2500 :2500-2570
GPSL1:1570-1610
GPSL2:1200-1300
GPSL3:1380-1400
Wi-Fi5.8GHz:5725-5850
VHF:135-174
UHF:400-470
RC433 :433
RC315 :315
CDMA450 :450-470
MHz Customized Output Power 10W 20W 30W 40W 50W 100W 200W

(We can do 5.8G jammer module 50W 40W )
2 Work Temperature -10~+75
3 Max Output Power 100 W
4 Work Voltage DC24 V
5 Max Gain 50±1 dB
6 Flatness ±3 dB
7 Max Current 10 A
8 Output VSWR ≤1.5
9 Output Connector N/F 50Ω
10 Power Amplifier Efficiency 43.8   When Max Output
11 Switch Control High Low Level Current V 0V off /0.6 on
12 Standing Wave Protection OK
13 Temperature Protection 75°
14 Product Size 220*115*25 mm Box size: 260*135*40 mm
15 Weight  1.03 Kg with Box





Customized 100W 200W RF Jammer Module For Different Frequency 0Customized 100W 200W RF Jammer Module For Different Frequency 1

Customized 100W 200W RF Jammer Module For Different Frequency 2



Customized 100W 200W RF Jammer Module For Different Frequency 3



Customized 100W 200W RF Jammer Module For Different Frequency 4
