| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | SGS,ISO9001,ROHS |
| Model Number: | TX-JZ01 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated |
| Packaging Details: | Fumigation wooden case with alluminum alloy frame |
| Delivery Time: | In 2 work day |
| Payment Terms: | T/T,Paypal, Etc. |
| Supply Ability: | 5000pcs/month |
| Jamming Frequency: | Customized | Jamming Range: | Up To 3000 Meter |
|---|---|---|---|
| Size: | 53*41*23cm | Weight: | 35kg (not Including Antenna) |
| Case Type: | Die Case Alluminum Alloy | Output Power: | High Power 650W (customized) |
| High Light: | Remote Control Cell Signal Disruptor,RJ45 Prison Signal Jammer |
||
Outdoor Prison Cellphone Jammer with RJ45 IP Remote Control
TXtelsig JZ01 wireless signal jammer is developed specially for prisons and other large, sensitive facilities, such as military installations and government, etc.
Shield range: 360 degree coverage, 200-300meter (3000meter for drone)
Shield signal: 2g, 3g, 4g, 5g, Wifi, VHF, UHF, drone, GPS, etc. iDen, TDMA, CDMA, GSM, UMTS, DCS, PHS, PCS, 3G,4G LTE,5G, Wi-Fi ,Bluetooth,GPS AMPS, N-AMPS, NMT, TACS, etc. (1-18 channels can be modified or added )
Output power: 190W (Max 650W )
Antenna: 4 directional antenna
Case: IP65 waterproof level die cast aluminum alloy
Network connection RJ45: computer, APP, drone detection system
* Efficient cooling system ensures long working hours
* We self also develop RF jammer modules, VCO, Gain Block, Other Accessories with wholesale competitive cost and fast delivery.
| Model | JZ-01 Prison Cellphone Jammer |
| Jamming frequencies | Cell Phone |
| WIFI | |
| GPS | |
| Drone , Other customized | |
|
1-18 Channels by different country and specific need) |
|
| Jamming radius |
1) 200-300meter for Cell Phone Signal,etc 2) 2000-3000meter for Drone Signal etc. |
| Power supply | AC Power plug |
| Total output power | 190W or customized (can > 650W) |
| Voltage | AC100-240V DC12V |
| Operating temperature | -40℃ to +70℃ |
| Operating humidity | 5% to 80% |
| Device size | 53*41*23cm |
| Device weight | 35kg ( not including antenna ) |
* 4pcs 360 degree High gain 16dBi directional antenna
* IP65 level bad environment protection Die cast aluminum alloy case
* RF jamming modules inside with original integrated circuit
* Other accessories available
* Real Scene Installation Photo
|
|
|
|
|
|
