| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | SGS, ISO9001 |
| Model Number: | YP163038 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated |
| Payment Terms: | L/C, T/T, Paypal,etc. |
| Frequency Range: | 1400-1800MHz | Gain (Typ): | 30dB |
|---|---|---|---|
| Operation: | 3.3-5.5V | Quiescent Current: | 12mA |
| Type: | Professional Amplifier,Mini Amplifier,Home Amplifier | Power Supply: | 220V/50Hz,12V 1.67A,220V |
| High Light: | radio frequency amplifier,mmic power amplifier |
||
TXtelsig YP163038 RF Amplifier 1.6GHz 6W GaAs MMIC Power Amplifier 1400-1800MHz
The YP163038 is a high-power, high-efficiency Power Amplifier intend for BDS Satellite Communication and Navigation. The Power Amplifier provides a typical power gain of 30 dB and saturation power of 38dBm with CW input, typical quiescent bias condition is 5.0V at 12mA. The device is manufactured on an advanced InGaP/GaAs Heterojunction Bipolar Transistor (HBT) process. The YP163038 is assembled in a 20-pin, 5mm×5mm, QFN package, it is internally integrated with ESD protection unit.
Features
■ 1.4~1.8GHz Frequency Range
■ 30dB Power Gain (Typ)
■ 38dBm Saturation Output Power
■ 10dB Input Return Loss
■ 3.3~5.5V Operation
■ 12mA Quiescent Current
■ Integrated Output Power Detector
■ Integrated ESD Protection Unit
■ Advanced InGaP/GaAs HBT Technology
Applications
■ BDS Satellite Communication and Navigation
■ Unmanned Aerial Vehicle System
Ordering Information
■ YP163038 1.6GHz Power Amplifier Chip
■ YP163038-EVB 1.6GHz YP163038 Evaluation Board
Caution! ESD Sensitive Device
ESD Rating: Class1C
Value: Passes≥1000V min.
Test: Human Body Model (HBM)
Standard: JEDEC Standard JESD22-A114
ESD Rating: Class IV
Value: Passes ≥1000V min.
Test: Charged Device Model (CDM)
Standard: JEDEC Standard JESD22-C101
MSL Rating: Level 3 at +260 °C convection
reflow
Standard: JEDEC Standard J-STD-020
| Parameter | Rating | Unit |
| Input RF Power | 10 | dBm |
| Supply Voltage | -0.5 to +6.0 | V |
| Bias Voltage | -0.5 to +3.0 | V |
| DC Supply Current | 3500 | mA |
| Operating Ambient Temperature | -40 to +85 | °C |
| Storage Temperature | -40 to +150 | °C |
| Pin Description | ||
| Pin No. | Symbol | Description |
| 3 | RF IN | RF input |
| 7, 9 | VR1&2, VR3 | Bias current control voltage |
| 18 | VCCB | Supply voltage for bias |
| 8 | VCTR | Power level control voltage |
| 11, 12, 13, 14, 15 | RF OUT (VCC3) | RF output and stage 3 collector voltage |
| 16 | VCC2 | Stage 2 collector voltage |
| 17 | PDET | Power detect |
| 18 | VCCB | Supply voltage for bias |
| 19 | VCCD | Supply voltage for power detector |
| 20 | VCC1 | Stage 1 collector voltage |
| 1, 2, 4, 5, 6, 10 | NC/GND | No connection or ground |
